PCM-3718H / PCM-3718HG

The PCM-3718H / 3718HG is a high performance multifunction data acquisition module that attaches to the PC/104 connector on your CPU card or PC/104 module. It offers 12-bit A/D conversion and digital input/output. The automatic channel scanning circuitry and the on-board SRAM lets you perform multiple-channel A/D conversion with DMA and individual channel gains.

Features

  • 16 single-ended or 8 differential analog inputs
  • 12-bit A/D converter, up to 100 KHz sampling rate with DMA transfer
  • Two 8-bit digital input/output TTL level channels

Overview

The PCM-3718H / 3718HG is a high performance multifunction data acquisition module that attaches to the PC/104 connector on your CPU card or PC/104 module. It offers 12-bit A/D conversion and digital input/output. The automatic channel scanning circuitry and the on-board SRAM lets you perform multiple-channel A/D conversion with DMA and individual channel gains.

Specifications

Characteristics
Module
  • Channels: 16 single-ended or 8 differential inputs
  • Resolution: 12 bits
  • Input Range: Bipolar: ±10, ±5, ±2.5, ±1.25, ±0.625
  • (PCM-3718H): Unipolar: 0 ~ 10,0 ~ 5,0 ~ 2.5,0 ~ 1.25
  • Input Range: Bipolar: ±10, ±5, ±1, ±0.5, ±0.1, ±0.05, ±0.01, ±0.005
  • (PCM-3718HG): Unipolar: 0 ~ 10, 0 ~ 1, 0 ~, 0 ~ 0.01

DIGITAL INPUT/OUTPUT

  • Channels: two 8-bit TTL-level Digital I/O channels
  • Input Voltage:
    o Logic 0: 0.8 V max.
    o Logic 1: 2.0 V min.
  • Output Voltage:
    o Logic 0: 0.33 V max. @ 6mA (sink)
    o Logic 1: 3.84 V min. @ 6mA (source)
  • Power Requirements: +5 V, ±5 % tolereance on power supply
  • Size / Weight: 96 mm x 90 mm (3.8" x 3.5"), 0.084 kg (0.185 lb)
  • Operating Temperature: 0° ~ 60° C (32° ~ 140° F)
  • Storage Temperature: -40° ~ 85° C (-40° ~ 185° F)
  • Operating Humidity: 0% ~ 90% relative humidity, non-condensing

Pricing

(Single Unit Pricing. Includes: Integration, Setup,Testing, & Enhanced Support)

Product # Description Price
PCM-3718H 16 CH., 100 KHZ, 12 BIT A/D $277.00
PCM-3718HG 16 CH., 100 KHZ, 12 BIT A/D, High Gain $277.00
