PCM-3680I

The PCM-3680I provides CAN capabilities for devices with a PCI/104 module interface.

Features

  • 16 single-ended or 8 differential A/D inputs, switch selectable
  • 12-bit A/D converter, up to 250 kHz sampling rate
  • Programmable gain for each input channel
  • Automatic channel/gain scanning
  • Onboard ring buffer for analog input and output
  • Software selectable Bipolar/Unipolar analog input ranges
  • 16 digital inputs and 16 digital outputs, TTL compatible
  • Two 12-bit analog output channels
  • Onboard programmable counter
  • Three 24-bit event counters
  • BoardID switch

Overview

The PCM-3680I provides CAN capabilities for devices with a PCI/104 module interface.

Specifications

Characteristics
Module
  • Ports: 2
  • CAN controller: SJA-1000
  • CAN transceiver: 82C250
  • Signal support: CAN_H, CAN_L
  • Protocol: CAN2.0 A/B
  • Speed: Up to 1 Mbps programmable transfer rate
  • CAN Frequency: 16 MHz
  • Isolation Protection: 2,500 VDC
  • Power consumption: +5 V @ 400 mA typical, 950 mA max.
  • Connectors: 4 x 10 pin box header
  • Operating temperature: -40 ~ 85° C(-40 ~ 185° F)
  • Dimensions: 90 mm x 96 mm (3.6" x 3.8")

Pricing

(Single Unit Pricing. Includes: Integration, Setup,Testing, & Enhanced Support)

Product # Description Price
PCM-3680I-0 PCI/104 CAN Interface Module $213.00
