SIB-R4760

  •  Qualcomm ARM® Cortex®-A53 APQ8016 Quad core up to 1.2 GHz
  •  Onboard 1GB/2GB LPDDR3 memory and 8GB eMMC
  •  1 HDMI, 1 RS-232/422/485, 1 GbE, 4 USB 2.0, 8 GPIO
  •  Highly intergrated on-board wireless connectivity - Wi-Fi, BT, and GNSS
  •  Connevtivity expansion capability - M.2, mini-PCIe
  •  Wide voltage range DC power input
  •  Support Android, Linux and Debian

EPC-R4760 is an ARM-based Box Computer powered by Qualcomm ARM® Cortex®-A53 APQ8016 processor that supports full HD display and intergrades onboard wireless solution
– Wi-Fi, BT and GPS. EPC-R4760 also features mini PCIe, M.2, and SIM card slots for expanding connectivity capability, like 3G, 4G/LTE modules. Equipped with complete Android,
Linux and Win10 IoT core BSPs, this box computer enables customers to easily develop unique applications on a specific OS.

Features

  •  Qualcomm ARM® Cortex®-A53 APQ8016 Quad core up to 1.2 GHz
  •  Onboard 1GB/2GB LPDDR3 memory and 8GB eMMC
  •  1 HDMI, 1 RS-232/422/485, 1 GbE, 4 USB 2.0, 8 GPIO
  •  Highly intergrated on-board wireless connectivity - Wi-Fi, BT, and GNSS
  •  Connevtivity expansion capability - M.2, mini-PCIe
  •  Wide voltage range DC power input
  •  Support Android, Linux and Debian

Overview

EPC-R4760 is an ARM-based Box Computer powered by Qualcomm ARM® Cortex®-A53 APQ8016 processor that supports full HD display and intergrades onboard wireless solution
– Wi-Fi, BT and GPS. EPC-R4760 also features mini PCIe, M.2, and SIM card slots for expanding connectivity capability, like 3G, 4G/LTE modules. Equipped with complete Android,
Linux and Win10 IoT core BSPs, this box computer enables customers to easily develop unique applications on a specific OS.

Manuals
Data Sheets
EPC-R4760 Datasheet.pdf
Download (PDF)

Specifications

Processor
CPU
Qualcomm Quad-core ARM® Cortex® A53 APQ8016
Clock Speed
1.2 GHz
Memory
RAM
On-board 1GB / 2GB
RAM Type
LPDDR3
Primary Flash
8GB onboard
Secondary Flash
SD Socket
Memory Misc.

LPDDR3 1066MHz
Primary IO
GPIO
8 x GPIO via D-SUB 9 (3.3V TTL level)
Disk Interface
SD CARD
Audio
HDMI audio
Video Out
HDMI
Ethernet
1x 10/100/1000 BaseT Ethernet
USB
2x USB 2.0
Serial Ports
1x RS-232, 1x RS-232/422/485
Primary I/O Misc.

HDMI 1 HDMI, 1920 x 1080 at 60Hz
H/W Video Codec
Encode: 30 fps 720p (H.264 Baseline/MPEG-4)
30 fps 1080p (MPEG-4/H.264/VP8/H.263)
Decode: 30 fps 1080p (MPEG-4/H.264/H.263/DivX/MPEG2/VC1/Soreson/VP8)
Secondary IO
Secondary I/O Misc.

Power Supply Voltage 9-36V
Power Type DC-in
Power Consumption 6.2W
Expansion
Bus Misc.
  • M.2 1 x M.2 2230 Key.E
  • mini PCIe 1x Full size mini PCIe slot (USB signal only)
  • SIM 1 x mini-SIM slot
Misc
Operating Systems
EMAC OE Linux, Android
Operating Systems Compatibility

Debian

Mechanical and Environmental

Dimensions
Size
7.4" ×5.9" ×1.54" (187mm × 149mm × 39mm)
Power Requirements
Power Misc.
  • Power Type DC-in
  • Power Supply Voltage 9-36V
  • Power Consumption 6.2W (Typical)
Environmental
Low Operating Temperature0 C (32 F)
High Operating Temperature40 C (104 F)
Upper Operating Humidity
95%

Pricing

Pricing correct as of January 2021. Please contact EMAC for Current Pricing and Lead Time. Due to volatility in the electronics industry pricing is subject to change.

OEM / Quantity Pricing Available on Request - Less Services

(Single Unit Pricing. Includes: Integration, Setup,Testing, & Enhanced Support)

Product # Description Price
Build to Order
SIB-R4760-Q00R1 EPC-R4760 APQ8016 Quad Core / 1GB DDR system $392.00
SIB-R4760-QW0R1 EPC-R4760 APQ8016 Quad Core / 2GB DDR system $412.00
