Single Board Computers |
|
|
|
|
|
|
|
This Web-Page contains a selection guide to help you locate x86 based peripherals. In EMACs quest to provide our customers with one stop SBC shopping, we offer a large number of add on Expansion Boards, Flash Disks, Hard Drives, Memory, Enclosures, Power Supplies and just about anything else you can think of. If you do not find an item on our web-site feel free to give us a call and I am sure we can help you with your requirements The most common method for expanding an embedded x86 system is through the use of PC/104 modules. EMAC has Data Acquisition & Control, Communications, and Expansion modules allowing the customer to enhance their systems. When using EMAC's Data Acquisiton and Control modules be sure to reference our SBC Interfacing Guidelines white paper for helpful interfacing information.
|
|
Data Acquisition
and Control I/O
|
|
| PCM-3712 | 2 Channel Analog Output Module |
| PCM-37E12 |
32 Channel Digital I/O, 24 Channel A/D Input, 4 Channel D/A Output, 1 RS-232, 1 RS-232/485, 1 CAN port, Keypad Interface, LCD Interface |
| PCM-3718 | 16 Channel, 12 Bit, 100 kHz A/D Module with 2 Digital Ports |
| PCM-3724 | 48 Channel Digital I/O Module |
| PCM-3725 | 8 Channel Isolated Digital Input & 8 Channel Relay Output Module |
| PCM-3730 | 8 Channel Isolated Digital Input & 8 Channel Isolated Output Module |
|
Communications
|
|
| PCM-3292 | 12 Channel GPS Module |
| PCM-3601 |
56K Fax/Modem Module |
| PCM-36E06 | Advanced Communication Module (GSM/GPRS, GPS, Modem, Serial) |
| PCM-3610 | Isolated RS232/422/485 Dual Port Serial Module |
| PCM-3614/8 | 4/8 Port RS-422/485 Module with Auto Switch |
| PCM-3640 | Four Port RS-232 Serial Module |
| PCM-3643 | 4/8 Port RS-232 Module |
| PCM-3663 | Dual 10/100 BaseT PC/104+ Module |
| PCM-3665 | Dual 10/100/1000 BaseT PC/104+ Module |
| CAN Bus Interface Module | |
|
Expansion
|
|
| PCM-3112 | PCMCIA PC/104 (16-bit) Module with 2 Slots |
| PCM-3115 | PCMCIA/Cardbus (32-bit) PC/104+ Module with 2 Slots |
| PCM-3116 | PC/104+ Dual Slot MiniPCI Module |
| PCM-2811 | Advanced Flat-Panel/CRT SVGA Module |
| PCM-3810 | Solid State Flash/EPROM/RAM Disk ModuleEOL |
| PCM-3835 | IDE Flash / CompactFlash Card Module |
| PCM-3840 | DiskOnChip 2000 Flash Disk Module |
|
Please Call or E-mail for pricing and availability.
|
|
|
Data Acquisition
and Control I/O
|
|
| PCM-3810I | 16 Channel Multifunction Module |
| PCM-3753I |
96 Channel Digital I/O Module |
| PCM-3761I | 8 Channel Isolated Digital Input & 8 Channel Relay Output Module |
| PCM-3730I | 16 Channel Isolated Digital Input & 16 Channel Isolated Output Module |
| PCM-3813I | 32 Channel Isolated Analog Input Module |
|
Communications
|
|
| PCM-3680I | CAN Bus Interface Module |
| PCM-3614I/8I |
4/8 Port RS-232/422/485 Module |
| PCM-3641I/2I | 4/8 Port RS-232 Module |
|
Please Call or E-mail for pricing and availability.
|
|
|
MicroBox Chassis
|
|
| MicroBox Chassis fits most Half-EBX (4.0" x 5.75") Boards | |
| MicroBox Chassis fits most EBX (8.0" x 5.75") Boards | |
| MBPC-400 | MicroBox Chassis fits PCM-95xx Series EBX (8.0" x 5.75") Boards |
| EBPC-5250 | MicroBox Chassis fits PCM-95xx Series EBX (8.0" x 5.75") Boards |
|
SBC Slot MicroBox
Chassis
|
|
| MicroBox Chassis w/ 60w P/S & 4-Slot PCI or ISA Backplane | |
| IPC-6806SP5 | MicroBox Chassis w/ 100/150w P/S & 5/6-Slot PCI or ISA Backplane |
|
Power Supplies
|
|
| PER-PWR-00041 | 120 VAC to PC FDD/HDD +5/+12 VDC, 30 Watt |
| PS-50A | 120/240 VAC to +5/+12 VDC, 50 Watt END OF LIFE |
| PS-55A | 120/240 VAC to +5/+12 VDC, 55 Watt END OF LIFE |
| PER-PWR-00020 | 120/240 VAC to PC FDD/HDD, AT +5/+12 VDC, 65 Watt Open Frame PS |
| PER-PWR-00008 | 120/240 VAC, 150 W ATX+24P P4 1U Mini Enclosed Power Supply |
| PER-PWR-00010 | 120/240 VAC, 200 W ATX P4 1U Mini Enclosed Power Supply |
| PCM-P50 | 50 W DC to DC PC/104 Power Supply Module |
| PER-PWR-00005 | ATX 150W 24v DC 1U P.S. |
|
Single and Segmented
Passive Backplanes
|
|
| PCA-6104P4 | 4 Slot w/ 4-PCI for PCI-6771F |
| PCA-6104P5 | 5 Slot w/ 5-PCI for PCI-6771F |
|
BP-202SG-P1
|
2 Slot w/ 1-PCI, and 1-PICMG (ARC-6102B Only) |
|
BP-203SI
|
3 Slot w/ 3-ISA |
| BP-204SI | 4 Slot w/ 4-ISA |
| BP-204SG-P1 | 4 Slot w/ 1-PCI, 2-ISA, and 1-PICMG |
| BP-204SS-P2 | 4 Slot w/ 2-PCI, 1-ISA, and 1-PISA |
|
BP-205SG-P2
|
5 Slot w/ 2-PCI, 2-ISA, and 1-PICMG (ARC-6205B Only) |
| BP-206SG-P3 | 6 Slot w/ 3-PCI, 2-ISA, and 1-PICMG |
| BP-206SI | 6 Slot w/ 6-ISA |
| BP-206SS-P4 | 7 Slot w/ 4-PCI, and 3-PISA |
|
BP-208SI
|
8 Slot w/ 8-ISA |
|
BP-208SG
|
8 Slot w/ 3-PCI, 4-ISA, and 1-PICMG |
| BP-209SG | 9 Slot w/ 4-PCI, 3-ISA, and 2-PICMG |
|
BP-212SI
|
12 Slot w/ 12-ISA |
|
BP-213DG
|
14 Slot 2-Segment w/ 3-PCI, 2-ISA, and 2-PICMG / 4-PCI, 2-ISA, and 1-PICMG |
|
BP-214SG-P4
|
14 Slot w/ 4-PCI, 8-ISA, and 2-PICMG |
|
BP-214SI
|
14 Slot w/ 14-ISA |
|
BP-214SG-P7
|
14 Slot w/ 7-PCI, 5-ISA, and 2-PICMG |
|
BP-214SS
|
14 Slot w/ 4-PCI, 8-ISA, and 2-PISA |
| BP-214DI | 14 Slot 2-Segment w/ 6-ISA / 8-ISA |
|
BP-219SG
|
19 Slot w/ 4-PCI, 13-ISA, and 2-PICMG |
|
BP-220SI
|
20 Slot w/ 20-ISA |
|
BP-220DI
|
20 Slot 2-Segment w/ 10-ISA / 10-ISA |
|
BP-220QI
|
20 Slot 4-Segment w/ 5-ISA / 5-ISA / 5-ISA / 5-ISA |
|
Please Call or E-mail for pricing and availability.
|
|
|
Processors (CPUs)
|
Hard Disk Drives
|
| Intel Pentium 4 (Socket 478) | 2.5" IDE HDDs to 80 GB |
| Intel Pentium 4-M (Socket 479) |
3.5" IDE HDDs to 300 GB
|
| Intel Celeron M | |
| Intel Pentium III (Socket 370) |
EmbedDisk
|
| Intel Celeron (Socket 370) |
Compact Flash
|
|
System Memory (RAM)
|
|
|
240 pin DIMM, DDR2
|
Embedded Linux 2.6 (Modified Debian) |
|
184 pin DIMM, DDR |
ROM-DOS (v6.22, v7.1) |
|
168 pin DIMM, PC100/133 |
MS-DOS (v6.22 embedded) |
| 200 pin SODIMM DDR & DDR2 | Windows CE.net |
| 144 pin SODIMM, PC100/133 | Windows XP Embedded |
|
Peripherals
|
|
| PS/2-AT Compatible Keyboards | |
| PS/2 Mouse | |
| 1.44MB 3.5" FDD | |
|
Please Call or Email for Pricing and Availability.
|
|
