LCD Character Displays

These displays have a full character set including an upper and lower case alphabet with arabic numbers, Greek and math symbols and more. There are also 8 user-definable characters with each one having 5x8 dots wich can be reprogrammed dynamically to emulate graphics type LCD displays. They come in a variety of formats such as 1x16 (1 line by 16 characters), 2x16, 2x20, 4x20, and 2x40, among others, and are available with LED backlighting. MTBASIC and E-FORTH provide built-in high level support for simple ASCII output. EMAC also provides drivers written in assembly language.

E020-30	20 Character 2x Line LCD Display
E020-31	20 Character 2x Line LCD Backlit Display
E020-32	20 Character 4x Line LCD Display
E020-33	20 Character 4x Line LCD Backlit Display
E020-24	240 x 128 Backlit Graphic LCD Display (EPAC 3000 and 3000G2 ONLY)
E060-01	Remote Access Device

KEYPADS

Tactile-dome membrane matrix keypads are available in 3 by 4 telephone style and 4 by 4 hex format. They have mounting hole and a flange to allow for flexible mounting configurations.

E020-25	12 Key Membrane Telephone-Style Keypad
E020-21	16 Key Membrane HEX-Style Keypad

E020-08	EPROM Programmer Board
E010-03	Smart Clock w/ Clock/Calender 32 K by 8
E010-04	Smart Clock w/ Clock/Calender 128 K by 8 (Requires 128 K RAM Upgrade)
E010-14	Smart Clock w/ Clock/Calender 512 K by 8 (Micropac 180 only)
E010-05	Smart Socket (Battery Backed RAM) 32 K by 8
E010-07	Smart Socket (Battery Backed RAM) 128 K by 8 (Requires 128 K RAM Upgrade)
E010-13	Smart Socket (Battery Backed RAM) 512 K by 8 (Micropac 180 only)
E010-16	Flash Memory 128 K by 8 (Micropac 180/535 Only)
E010-17	Flash Memory 512 K by 8 (Micropac 180 only)

Also see our Software and Tools Page!

E030-07	ANSI Cross C Compiler With Z180 Assembler & Linker
E030-06	8085 / Z80 / 64180 / Z180 Assembler & Linker
E030-1X	DDS ANSI C Subset Compiler With Assembler For All Micros
E030-08	ANSI C Compiler With Assembler & Linker For 68HC11
E030-09	ANSI C Compiler With Assembler & Linker For 68HC16
E030-01	ANSI C Compiler With Assembler & Linker (IDE) For 8051 / 80535
E030-02	Assembler IDE For Windows 68HC16
E030-31	Z180 In-Circuit Emulator & Debugger
