System on Module Selection Guide














Need help in making a selection?
For an EMAC authored article on selecting an SBC click here.
For an Presentation of the SoM approach, benefits & features click here.



System on a module (SoM) is an ideal alternative to custom engineering. With an SoM approach you get the best of aspects of both buying an Off-The-Shelf Single Board Computer (SBC) and of a Custom Engineered solution. With Off-The-Shelf standard components such as a generic carrier board and SOM module, it is possible to start development on your software applications before the custom carrier board is complete; thus offering a reduced time to market for your system.

A System on Module (SoM) is comprised of a small processor module with CPU bus accessibility and standard I/O functionality. The SoM module does not have any connectorization and is designed to be plugged into a Carrier Board. The Carrier board contains the I/O connectors as well any other I/O requirement not provided on the SoM itself. The SOM approach offers reduced risk of an End-of-life product due to a memory, flash, chipset or CPU going end-of-life. With the ability to swap in another CPU SOM board in the system can be running just as it was with no or minimal changes to the carrier board. This also offers scalability by offering a range of processor speeds and features in the same packages. These features offer scalability to allow a company to offer the same carrier board with multiple speed cores for similar products, allowing the economy of scale to bring down per-unit pricing.

This approach allows the customer to design a simpler and easier to build Custom Carrier Board, that meets the customer's I/O, dimensional, and connector requirements without having to worry about the processor, memory, and standard I/O functionality. The custom carrier can also reduce or eliminate complicated custom cabling, by providing prewired connectors to connect to other off the shelf cables. Thus reducing or eliminating the need for custom cable manufacturing and reducing final unit assembly time.

If the customer does not have the ability to design the Custom Carrier board in-house, EMAC's Custom to Order Service (COS) can economically produce a Custom Carrier for you. By utilizing a library of standard I/O modules EMAC can typically deliver Carrier prototypes in 1 to 2 months and also meet your production delivery needs in the future. EMAC also offers Off-The-Shelf Carrier boards for SoM evaluation and early software development. This provides the ability to have a marketable semi-custom product in as little as 6 weeks. By already starting custom software development work on generic off the shelf hardware which includes the same processor core, it has been possible to have your software ready or almost ready when the custom carrier is built.

There are two families of SoMs. The microcontroller family offers a very inexpensive and small size solution for Data Accusation and Control, Internet Appliance and Web applications. The x86 family offers PC compatibility with embedded features such as Flash Disk and LCD video. An advantage of the SoM design approach is that within each family of SoMs there are several processor choices. This allows the user to select a low-end processor for initial deployment and upgrade later to a higher end processor as features and need demands.

While all SoM modules run the most common operating systems, we specialize in our custom built Embedded Linux and Linux Open Embedded operating systems. We also offer customization of most commonly Embedded Microsoft operating systems: WindowsCE, WindowsXP, WindowsXP Embedded and MSDOS.

SoM Benefits

  • Faster time to market
  • Cost savings
  • Reduced risk
  • Scalable CPU choices
  • Decreased customer design requirements
  • Small footprint

Microcontroller SODIMM Modules

Name

CPU

Memory
Flash/RAM

Serial Ports

Digital I/O

Timers/ Counters

Bus Type

Size
(in.)

Other I/O

SoM-400EM

Dallas™ TINI®
DS80C400
30 MHz
8-Bit

Flash 2 MB
RAM 1-2 MB

3 TTL,
1 SPI

5 Inputs
5 Outputs

4, 16-bit Timer/ Counters,
Watchdog

144-pin SODIMM

2.66"
by
1.5"

10/100 BaseT Ethernet
Hardware SPI, CAN, Battery Back RAM,
1-Wire®
Real Time Clock

SoM-NE64M

FreeScale
MC9S12NE64
(64HCS12)
50 MHz
16-Bit

Flash 64 KB
RAM 8-512KB
EEPROM 32KB

2 TTL,
1 SPI,
1 I2C

16 Prog.
GP I/Os

4, 16-bit,
Timer/ Counters,
PWM/ Compare
Watchdog

144-pin SODIMM

2.66"
by
1.5"

10/100 BaseT Ethernet
A/D, 1-Wire®
Real Time Clock

SoM-5282M

FreeScale
Coldfire
MCF5282
66 MHz
32-Bit

Flash 4.5MB
RAM 16MB
64K NV RAM

3 TTL,
1 SPI,
1 I2C

16 Prog.
GP I/Os

4, 32-bit,
4, 16-bit,
Timer/ Counters,
PWM/ Compare
Watchdog

144-pin SODIMM

2.66"
by
1.5"

10/100 BaseT Ethernet
CAN, A/D,
Battery Back RAM,
Real Time Clock

SoM-536EM

Analog Devices
Blackfin DSP
ADSP-BF536
400/600 MHz
16/32-Bit

Flash 4MB
RAM 64MB
EEPROM 128KB

3 TTL,
1 SPI,
1 I2C

16 Prog.
GP I/Os

8, 32-bit,
Timer/ Counters,
PWM/ Compare
Watchdog

144-pin SODIMM

2.66"
by
1.5"

10/100 BaseT Ethernet
CAN, I2S, 1-Wire®
Battery Back RAM,
Real Time Clock

SoM-9260M

Atmel
ARM9 Jazelle
AT91SAM9260
200 MHz
32-Bit

Flash 64MB
RAM 128MB
EEPROM 128KB

6 TTL,
2 SPI,
1 I2C

32 Prog.
GP I/Os

6, 16-bit Timer/ Counters,
PWM/ Compare
Watchdog

144-pin SODIMM

2.66"
by
1.5"

10/100 BaseT Ethernet, SDIO
A/D, I2S Audio
USB 2.0 Host & Device
Real Time Clock

SoM-9G20M

Atmel
ARM9 Jazelle
AT91SAM9G20
400 MHz
32-Bit

Flash 1GB
RAM 64MB
DataFlash 4MB

7 TTL,
2 SPI,
1 I2C

32 Prog.
GP I/Os

6, 16-bit Timer/ Counters,
PWM/ Compare
Watchdog

144-pin SODIMM

2.66"
by
1.5"

10/100 BaseT Ethernet, SDIO
A/D, I2S, Audio
USB 2.0 Host & Device
Real Time Clock

SoM-9x25

Embedded Atmel
AT91SAM9X25
400 MHz

128 MB 133
MHz SDRAM, 2 GB
eMMC Flash &
8 MB of Serial Data Flash

6 RS485,
2 SPI,
1 I2C

32 Prog.
GP I/Os

3x, 32-bit Timers/Counters, PWM/ Compare
Watchdog,
20-bit timer,
12-bit counter

Local ARM Bus

2.66"
by
1.5"

10/100 BaseT Ethernet
A/D,
Battery Back RAM, Real Time Clock

SoM-9307M

Cirrus
ARM9
EP9307
200 MHz
32-Bit

Flash 64MB
RAM 128MB
EEPROM 128KB

3 TTL,
1 SPI,
1 I2C

32 Prog.
GP I/Os

1, 32-bit,
2, 16-bit Timer/
PWM/
Watchdog

200-pin SODIMM

2.66"
by
2.375"

10/100 BaseT Ethernet
A/D, I2S Audio
2D Video, Touchscreen,
USB 2.0 Host,
Real Time Clock

SoM-9G45M
/9M10

Atmel
ARM9
AT91SAM9G45
AT91SAM9M10
400 MHz
32-Bit

Flash 1 GB
RAM 256MB
DataFlash 4MB

5 TTL,
2 SPI,
2 I2C

32 Prog.
GP I/Os

6, 16-bit Timer/ Counters,
PWM/ Compare
Watchdog

200-pin SODIMM

2.66"
by
2.375"

10/100 BaseT Ethernet, SDIO
A/D, I2S Audio
Video w/codec, Touchscreen,
USB 2.0 Host & Device,
Real Time Clock

SoM-3517M

TI
ARM Cortex-A8
600 MHz
32-Bit

Flash 1 GB
RAM 512MB
eMMC Flash 4GB

4 TTL,
2 SPI,
2 I2C

16 Prog.
GP I/Os

11, 16-bit Timer/ Counters,
PWM
Watchdog

200-pin SODIMM

2.66"
by
2.375"

10/100 BaseT Ethernet, SDIO
A/D, I2S Audio
2D/3D Video, Touchscreen,
USB 1.1/2.0 Host & OTG,
Real Time Clock


SODIMM Carrier Boards

Name

CPU

Memory
Flash/RAM

Serial Ports

Digital I/O

USB

Bus Type

Size
(in.)

Other I/O

SoM-100ES

SoM-400
SoM-NE64
SoM-5282

MMC/SD
Flash Slot

2 RS232,
1 RS232/ 422/485

32
Digital
I/O
Lines

None

144-pin
SODIMM

4.0"
by
5.75"

10/100 BaseT Ethernet
Keypad, LCD, A/D, D/A
SPI, CAN, Modem,
1-Wire®

SoM-150ES

SoM-9260
SoM-9G45

MMC/SD
Flash Slot

4 RS232,
1 RS232/ 422/485

24
Digital
I/O
Lines

2 Host
1 Device

144-pin
SODIMM

4.37"
by
6.00"

10/100 BaseT Ethernet
Keypad, LCD, A/D, D/A
SPI, USB Host & Device
Audio In/Out

SoM-200ES

SoM-9307
SoM-3517

MMC/SD
Flash Slot

3 RS232,
1 RS232/ 422/485

24
Digital
I/O
Lines

2 Host
1 Device

200-pin
SODIMM

4.37"
by
6.00"

10/100 BaseT Ethernet
WQVGA LCD w/Touchscreen
SPI, USB Host & Device
Audio In/Out,

SoM-210ES

SoM-9307
SoM-9G45
SoM-3517

Micro SD
Flash Slot

2 RS232,
1 RS232/ 422/485

24
Digital
I/O
Lines

2 Host

200-pin
SODIMM

3.0"
by
4.8"

10/100 BaseT Ethernet
WQVGA LCD w/Touchscreen
CAN, SPI, I2C, A/D
Audio Beeper

SoM-212ES SoM-9G45
SoM-3517
Micro SD Flash Slot 3 RS232,
1 RS232/ 422/485
16
Digital
I/O
Lines
2 Host
1 OTG
200-pin
SODIMM
3.0"
by
4.8"
10/100 BaseT Ethernet
WQVGA LCD w/Touchscreen
CAN, SPI, I2C, A/D, Audio in/out
Audio Beeper, POE

SoM-250ES

SoM-9G45M
/9M10
SoM-3517

Micro SD
Flash Slot

3 RS232,
1 RS232/ 422/485

32
Digital
I/O
Lines

1 Host
1 OTG

200-pin
SODIMM

4.15"
by
7.55"

10/100 BaseT Ethernet
WVGA LCD w/Touchscreen
CAN, SPI,I2S
Audio Beeper, POE


PC-Compatible ETX Modules

Name

CPU

Memory
BIOS/RAM

Serial Ports

Disk
Interfaces

Video

Bus Type

Size
(in.)

Other I/O

SoM-4455

AMD
Geode LX800
500MHz

Award
512 MB
DDR RAM Max

1 Parallel
2 TTL

FDD/LPT,
2 EIDE Ultra DMA66

NS CX5536
CRT/LCD
4 - 64 MB shared

PCI/ISA

3.7" by 5.4"

100 BaseT Ethernet
KB/Mouse/IrDA
4 USB 2.0/Audio/LVDS
Optional TV-Out
Compact Flash
Watchdog

SoM-4463

Embedded Intel Atom
N450/D510
1.66 GHz,
Socket 479

Award
1GB DDR RAM Max

1 Parallel
2 TTL

EIDE,
FDD or
LPT

Intel Atom N450/ D510

PCI/ISA

3.7" by 4.5 "

100 BaseT Ethernet
KB/Mouse/
4 USB 2.0/Audio/LVDS
Watchdog

SoM-4463 B1

Embedded Intel Atom
N455/D525

AMI
2GB DDR3 RAM Max for N455 and 4GB for D525 version

1 Parallel
2 TTL

2xEIDE
LPT/FDD

Intel Atom N455/ D525

PCI/ISA

3.7" by 4.5 "

100 BaseT Ethernet
KB/Mouse/
4 USB 2.0/Audio/CRT/LVDS
Watchdog


ETX Carrier Boards

Name

CPU

Memory
Flash

Serial Ports

Disk
Interfaces

Video

Bus Type

Size
(in.)

Other I/O

SoM-DB4400

EOL

Any ETX
SoM

Compact
Flash

1 Parallel
2 RS232

FDD/LPT,
Compact Flash,
IDE

DB15,
LCD

PCI/ISA
Slots

12"
by
7.5"

100 BaseT Ethernet
KB/Mouse
2 USB/Audio


ETX Carrier Boards

Name

CPU

Memory
BIOS/RAM

Serial Ports

Disk
Interfaces

Video

Bus Type

Size
(in.)

Other I/O

SoM-5786

Intel
Core Duo
Up to 2.2GHz

Award
4GB DDR2
RAM Max

8 USB

1 EIDE
UDMA 100,
3 SATA

Intel GME965
CRT/LCD/LVDS
384 MB shared

PCIE,
PCI,
SMB,
LPC

3.74" by 4.92"
(Std)

1000 BaseT Ethernet
Audio
Watchdog

SoM-5788

Intel
Core i7
Up to 2.53GHz

AMI
8GB DDR3
RAM Max

8 USB

1 EIDE
UDMA 100,
3 SATA

Intel QM57, Gen 5.75
VGE/LVDS/HDMI

PCIE,
PCI,
PEG,
LPC

3.74" by 4.92"
(Std)

1000 BaseT Ethernet
Audio
Watchdog

SoM-6763

Intel
Atom Z530
1.6GHz

Award
2GB DDR2
RAM Max

8 USB

1 EIDE
UDMA 100

Intel ICH8-M
CRT/LCD/LVDS

PCIE,
PCI,
LPC

3.74" by 3.74"
(Micro)

1000 BaseT Ethernet
Audio/GPIO
Watchdog

SOM-7562

Intel
Atom N455
1.6GHz

AMI
1GB DDR3
RAM Max

8 USB

3 SATA

Embedded Gen3.5+ GFX Core
CRT/LVDS

PCIE,
SMB,
LPC

3.31" by 2.17"
(Nano)

1000 BaseT Ethernet
Audio/GPIO
Watchdog

CoM-U15

Intel
Atom Z530
1.6GHz

Award
1GB DDR2
RAM Max

8 USB

1 EIDE
UDMA 100,
2 SATA

Intel US15W
CRT/LCD/LVDS
256 MB shared

PCIE,
PCI,
SMB,
LPC

3.31" by 2.17"
(Nano)

1000 BaseT Ethernet
Audio/GPIO
Watchdog

CoM-TC Intel
Atom E680
1.6GHz
AMI
2GB DDR2
RAM Max

7 USB

1 PATA,
1 SATA

Intel E680 Integrated
SDVO/LCD/LVDS
up to 384MB shared/ DVMT 4.0

4-Bit SDIO, PCIE,
SMB,
LPC

3.74" by 3.74"
(Type 2)

1000 BaseT Ethernet
Audio/GPIO
Watchdog


ETX Carrier Boards

Name

CPU

Memory
Flash

Serial Ports

Disk
Interfaces

Video

Bus Type

Size
(in.)

Other I/O

SoM-DB5700

Any COM
SoM

Compact
Flash

1 Parallel
2 RS232

FDD/LPT,
SATA,
EIDE

DB15,
Dual LVDS

PCIE,
Mini PCI,
PCI/ISA
Slots

12"
by
7.5"

100 BaseT Ethernet
1000 BaseT Ethernet
KB/Mouse
USB/Audio


ETX Carrier Boards

Name

CPU

Memory
BIOS/RAM

Serial Ports

Disk
Interfaces

Video

Bus Type

Size
(in.)

Other I/O

SoM-4450
EOL

Geode GX1
300MHz

Award
256 MB SDRAM RAM Max

1 Parallel
2 TTL

FDD/LPT,
2 EIDE Ultra DMA33

NS CX5530
CRT/LCD
1- 4 MB shared

PCI/ISA

3.7" by 5.4"

100 BaseT Ethernet
KB/Mouse/ IrDA
2 USB/Audio/LVDS
Compact Flash
Watchdog

SoM-4451
EOL

SiS 552
200MHz

Award
256 MB SDRAM RAM Max

1 Parallel
2 TTL

FDD/LPT,
1 EIDE Ultra DMA66

SiS 552
CRT/LCD
32- 64 MB shared

PCI/ISA

3.7" by 5.4"

100 BaseT Ethernet
KB/Mouse/ IrDA/TV-Out
2 USB/Audio/LVDS
Watchdog

SoM-4472
EOL

VIA Eden/Ezra 400/800 MHz

Award
512 MB SDRAM RMA Max

1 Parallel
2 TTL

FDD/LPT,
2 EIDE Ultra DMA33

VIA
Twister™
Savage4™
CRT/LCD
8 - 64 MB MB shared

PCI/ISA

3.7" by 5.4"

100 BaseT Ethernet
KB/Mouse/ IrDA
4 USB/Audio/LVDS
NTSC/PAL
Watchdog

SoM-4475
EOL

Intel® ULV Celeron™ 400 Pentium® III 650/933 MHz

Award
512 MB SDRAM RAM Max

1 Parallel
2 TTL

FDD/LPT,
2 EIDE Ultra DMA66

VIA Twister™ Savage4™
CRT/LCD
8 - 64 MB shared

PCI/ISA

3.7" by 5.4"

100 BaseT Ethernet
KB/Mouse/ IrDA
4 USB/Audio/LVDS
TV-Out NTSC/PAL
Watchdog

SoM-4481
EOL

Embedded Intel Pentium M
1.1 GHz,
1.6 GHz,

AMI
4GB DDR2 RAM Max

1 Parallel
2 SATAII

Enhanced 2 EIDE Ultra DMA66

Intel 855GV
CRT/LCD
8 - 64 MB shared

PCI/ISA

3.7" by 5.4"

100 BaseT Ethernet
KB/Mouse/ IrDA
4 USB 2.0/Audio/LVDS
Watchdog

SoM-4486
EOL

Embedded Intel Celeron
600 MHz

Award
1GB DDR RAM Max

1 Parallel
2 TTL

Enhanced 2 EIDE Ultra DMA66

Intel 852GV
CRT/LCD
8 - 64 MB shared

PCI/ISA

3.7" by 5.4"

100 BaseT Ethernet
KB/Mouse/ IrDA
4 USB 2.0/Audio/LVDS
Watchdog

SoM-6760
EOL

Intel Atom N450/D510
1.66GHz

AMI
4GB DDR2
RAM Max

8 USB

1 EIDE
UDMA 100

Intel US15W
CRT/LCD/LVDS
256 MB shared

PCIE,
PCI,
SMB,
LPC

3.74" by 3.74"
(Micro)

10/100 BaseT Ethernet
Audio/GPIO
Watchdog


Descriptions and specifications subject to change without notice.



Copyright © EMAC, Inc.
All Rights Reserved
