SBC Selection Guide



Operating SystemsHome Page PC/104 ModulesCPU Cards Panel PCsStandalone SBCs




Need help in making a selection? For an EMAC authored article on selecting an SBC click here.

EMAC offers Free Integration & Full Functional Testing for each order!

EMAC can provide Enclosures, I/O Modules, Peripherals, Memory, and Operating Systems (OSs) for most of our PC-SBCs. EMAC supports and can install the following Operating Systems on Hard Drive or Flash Disk: Linux, Real Time Linux, DOS, Windows CE, and Embedded Windows XP. In addition, EMAC can provide Board Support Packages (BSPs) for our SBCs using most of the aforementioned Operating Systems. Integration of the SBC into an enclosure, adding memory or CPU, loading an OS, in most cases is free with the purchase of the SBC and related components. Addionally EMAC has LCD- Panel Kits with Touchscreen options, allowing our SBCs to utilize an LCD for video output and a touchscreen replacement of a mouse for input. The LCD Panel Kit with the Touchscreen option in conjunction with the Flash Disk, makes for a Solid State Embedded computer system that is ideal for rugged, low downtime environments. If you cannot find exactly what you need from our large Off-The-Shelf selection, EMAC can Customize any hardware or software component, and additionly offers driver development and software application programming, providing you with the perfect fit for their SBC application needs.



486 Single Board Computer Products

Name

CPU

Memory
BIOS/RAM Max.

Parallel/
Serial Ports

Disk
Interfaces

Video

Exp.
Bus Type

Form
Factor

Other I/O

PCM-53E52

AMD ELAN SC520 - 133MHz

General Software/
128 MB SDRAM
on-board

1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485

FDD,
Enhanced
IDE

N/A

PC/104+

Half EBX
5.75"x4.0"

10/100 Ethernet,
KB/Mouse ,
DiskOnChip®, Digital & Analog I/O

VSX-6127

Vortex SX 300MHz

AMI/
128 MB
DDR2
on-board

1 Parallel
SPP/EPP/ECP
7 RS232
1 RS232/485

1 EIDE (UDMA 100)

CRT/LCD
32MB

PC/104+

Half EBX
5.75"x4.0"

10/100 Ethernet,
USB 2.0, KB/Mouse,
Watchdog,
GPIO

VSX-6124

Vortex SX 300MHz

AMI/
128 MB
DDR2
on-board

1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485

FDD,
1 EIDE (UDMA 100)

CRT/LCD
32MB

ISA Bus PC/104+

Half Size ISA Card
7.3"x4.8"

10/100 Ethernet,
USB 2.0, KB/Mouse,
Watchdog,
GPIO

VSX-6154

Vortex SX 300MHz

AMI/
128 MB
DDR2
on-board

1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485

1 EIDE (UDMA 100)

CRT/LCD
32MB

PC/104+

PC/104
3.55"x3.78"

10/100 Ethernet,
USB 2.0, KB/Mouse,
Watchdog,
GPIO

VDX-6324

Vortex DX 800MHz

AMI/
512 MB
DDR2
on-board

1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485

FDD,
1 EIDE (UDMA 100)

CRT/LCD
32MB

ISA Bus PC/104+

Half Size ISA Card
7.3"x4.8"

10/100 Ethernet,
USB 2.0, KB/Mouse,
Watchdog,
GPIO, PWM

VDX-6327
/ 6328

Vortex DX 800MHz

AMI/
512 MB
DDR2
on-board

1 Parallel
SPP/EPP/ECP
7 RS232
1 RS232/485

FDD,
1 EIDE (UDMA 100)

CRT/LCD
32MB

PC/104+

Half EBX
5.75"x4.0"

10/100 Ethernet,
USB 2.0, KB/Mouse,
Compact Flash,
Audio, Watchdog,
GPIO, PWM

VDX-6350

Vortex DX 800MHz

AMI/
512 MB
DDR2
on-board

1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485

1 EIDE (UDMA 100)

N/A

PC/104

PC/104
3.55"x3.78"

10/100 Ethernet,
USB 2.0, KB/Mouse,
Watchdog,
GPIO, PWM

VDX-6353

Vortex DX 800MHz

AMI/
512 MB
DDR2
on-board

1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485

1 EIDE (UDMA 100)

CRT/LCD
LVDS
32MB

PC/104

PC/104
3.55"x3.78"

10/100 Ethernet,
USB 2.0, KB/Mouse,
Compact Flash,
Audio, Watchdog,
GPIO, PWM

VDX-6354

Vortex DX 800MHz

AMI/
512 MB
DDR2
on-board

1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485

1 EIDE (UDMA 100)

CRT/LCD
32MB

PC/104

PC/104
3.55"x3.78"

10/100 Ethernet,
USB 2.0, KB/Mouse,
Audio, Watchdog,
GPIO, PWM


Pentium Single Board Computer Products

Name

CPU

Memory
BIOS/RAM Max.

Parallel/
Serial Ports

Disk
Interfaces

Video

Exp.
Bus Type

Form
Factor

Other I/O

PCM-3353

AMD Geode LX800
500 Mhz

Award BIOS
1 Gig
DDR RAM

1 Parallel
SPP/ EPP/ ECP
3 RS232
1 RS232/485

FDD,
Enhanced
IDE
(UDMA 33)

AMD CS5536
CRT/LCD
4 - 64 MB Shared

PC/104+

PC/104
3.55"x3.78"

Dual 10/100 Ethernet, KB/Mouse, USB 2.0, Watchdog, CompactFlash™

PCM-5315

AMD Geode LX800
500 Mhz

Award BIOS
1 Gig
DDR RAM

1 Parallel
SPP/EPP/ECP
1 RS232
1 RS232/485

FDD,
Enhanced
IDE
(UDMA 33)

CX5536
CRT/LCD
1 - 16 MB Shared

PC/104
Mini PCI

Half EBX
5.75"x4.0"

Dual Ethernet, KB/Mouse, Audio, IrDA, USB 2.0, Watchdog,
LVDS, GPIO CompactFlash™

PFM-540I

AMD Geode LX800
500 Mhz

Award BIOS
1 Gig
DDR RAM

1 Parallel
SPP/ EPP/ ECP
3 RS232
1 RS232/485

FDD,
Enhanced
IDE
(UDMA 33)

AMD CS5536
CRT/LCD
4 - 64 MB Shared

PC/104

PC/104
3.55"x3.78"

10/100 Ethernet, KB/Mouse, USB 2.0, Watchdog, CompactFlash™

PFM-541I

AMD Geode LX800
500 Mhz

Award BIOS
1 Gig
DDR RAM

3 RS232
1 RS232/485

FDD,
Enhanced
IDE
(UDMA 33)

AMD CS5536
CRT/LCD
4 - 64 MB Shared

PC/104

PC/104
3.55"x3.78"

Dual 10/100 Ethernet, KB/Mouse, USB2.0, Watchdog, CompactFlash™

PCM-5536

AMD Geode™ LX 800
500MHz

Award Bios
1 Gig
DDR RAM
1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485
1 COM TTL only/ GPS
Enhanced
IDE
(UDMA 33)
AMD LX + TI SN 75 LVDS 83
CRT/LCD up to 254 MB shared
PC/104+
EPIC
6.5"x4.5"
Dual Ethernet, KB/Mouse, Audio, USB 2.0, Watchdog,
LVDS, GPIO,
CompactFlash™

PCM-5895

AMD Geode LX800
500 Mhz

Award Bios
512 MB
DDR RAM

1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485

FDD,
Enhanced
IDE
(UDMA 100)

CX5536
CRT/LCD
1 - 16 MB Shared

PC/104+ PCI Slot

Full EBX
8.0"x5.75"

Dual 10/100 Ethernet, Audio, IrDA, USB, CAN, Watchdog, GPIO
DiskOnChip
CompactFlash™

HSB-800I

AMD Geode LX800
500 Mhz

Award Bios
128 MB
DDR RAM

1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485

FDD,
Enhanced
IDE
(UDMA 33)

CX5536
CRT/LCD
1 - 16 MB Shared

ISA Bus PC/104

Half Size ISA Card
7.3"x4.8"

10/100 Ethernet, KB/Mouse, Audio, IrDA, USB 2.0, Watchdog, GPIO
CompactFlash™

PCM-9375 AMD Geode LX800
500 Mhz
Award BIOS 1 GB
DDR RAM
1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485
Enhanced
IDE
(UDMA 66)
SATA
AMD CS5536
CRT/LCD
4 - 64 MB Shared
PC/104 Half EBX
5.75"x4.0"
Dual Ethernet, KB/Mouse, Audio, Optional TV-Out, GPIO, USB 2.0, Watchdog, CompactFlash™
PCM-9388 Intel® Celeron™M
600 MHz,
or 1 GHz
Award Bios
1 Gig
DDR RAM
1 Parallel
SPP/EPP/ECP
1 RS232
1 RS232/485
Enhanced
IDE
(UDMA 33)
Intel 852G
Dual Display
CRT/LCD up to 64 MB shared
PC/104
Half EBX
5.75"x4.0"
10/100 Ethernet, KB/Mouse, Audio, USB 2.0, IrDA, Watchdog, CompactFlash™

VDX-6324

Vortex DX 800MHz

Award/
512 MB
DDR2
on-board

1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485

1 EIDE (UDMA 100)

CRT/LCD
32MB

ISA Bus PC/104+

Half Size ISA Card
7.3"x4.8"

10/100 Ethernet,
USB 2.0, KB/Mouse,
Watchdog,
GPIO, PWM

VDX-6327

Vortex DX 800MHz

Award/
256 MB
DDR2
on-board

1 Parallel
SPP/EPP/ECP
7 RS232
1 RS232/485

FDD,
1 EIDE (UDMA 100)

CRT/LCD
32MB

PC/104+

Half EBX
5.75"x4.0"

10/100 Ethernet,
USB 2.0, KB/Mouse,
Compact Flash, Watchdog,
GPIO, PWM

VDX-6354

Vortex DX 800MHz

Award/
512 MB
DDR2
on-board

1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485

1 EIDE (UDMA 100)

CRT/LCD
32MB

PC/104+

PC/104
3.55"x3.78"

10/100 Ethernet,
USB 2.0, KB/Mouse,
Audio, Watchdog,
GPIO, PWM



Pentium Single Board Computer Products

Name

CPU

Memory
BIOS/RAM Max.

Parallel/
Serial Ports

Disk
Interfaces

Video

Exp.
Bus Type

Form
Factor

Other I/O

PCM-3341
EOL

STPC Atlas 133MHz

Award/
64 MB
SDRAM
on-board

1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485

FDD
(Optional),
1 EIDE (UDMA 33)

Built-In
CRT/LCD
Shared

PC/104

PC/104
3.55"x3.78"

10/100 Ethernet, USB, KB/Mouse,
Watchdog, IrDA,
CompactFlash™

PCM-3348
EOL

STPC Consumer II 133MHz

Award/
64 MB
SDRAM
on-board

1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485

FDD,
1 EIDE (UDMA 33)

Built-In
CRT/LCD
Shared

PC/104

PC/104
3.55"x3.78"

10/100 Ethernet, KB/Mouse,
Watchdog, IrDA,
CompactFlash™

PCM-3372
EOL

VIA Eden V4
400/600 MHz &
1 GHz

Award Bios
1 Gig
DDR2 RAM

1 RS232
1 RS232/485

EIDE,
2 SATA

VIA CX700
CRT/LCD
64 MB Shared

PC/104+

PC/104
Extended
3.8"x4.5"

10/100 Ethernet, KB/Mouse, Audio, USB2.0, LVDS, Watchdog, GPIO
CompactFlash™

PCM-3375
EOL

VIA Mark
533 MHz

Award Bios
256 MB
SDRAM

1 Parallel
SPP/EPP/ECP
1 RS232
1 RS232/485

FDD
(Optional),
Enhanced
IDE
(UDMA 100)

VIA 686B
CRT/LCD
8 - 32 MB Shared

PC/104

PC/104
3.55"x3.78"

10/100 Ethernet, KB/Mouse, IrDA, USB, LVDS, Watchdog,
CompactFlash™

SBC-411/E
EOL

Intel
486® DX4-100

AMI/
64 MB
EDO

1 Parallel
SPP/EPP/ECP
2 RS232

FDD,
Enhanced IDE

N/A

ISA Bus
PC/104

Half Size ISA Card
7.3"x4.8"

10 BaseT Ethernet,
KB/Mouse,
Watchdog, DiskOnChip®

HSB-440I
EOL

STPC Atlas 133MHz

Award/
64 MB
SDRAM
on-board

1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485

FDD,
1 EIDE (UDMA 33)

Built-In
CRT/LCD
Shared

ISA Bus
PC/104

Half Size ISA Card
7.3"x4.8

10/100 Ethernet, USB, KB/Mouse,
Watchdog, IrDA,
GPIO, DiskOnChip®
CompactFlash™

HSB-813s
EOL

Socket 479 Intel® Celeron®/ Pentium M up to
2.13 GHz

Award Bios
2 Gig
DDR RAM

1 Parallel
EPP/ECP
1 RS232
1 RS232/485

FDD,
2 EIDE
(UDMA 100) 2 SATA

Intel 855G
Dual Display
CRT/LCD up to 128 MB shared

PISA Bus
(ISA/PCI)
Mini PCI

Half Size PISA
Card
7.3"x4.8"

Dual Ethernet,
Gigabit Ethernet, KB/Mouse, Audio, USB 2.0,
LVDS, Watchdog, CompactFlash™

SBC-456/E
EOL

Intel
486® DX4-100

AMI/
128 MB
EDO

1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485

FDD,
Enhanced IDE

SM-712
CRT/LCD
2 MB


ISA Bus
PC/104

Half Size ISA Card
7.3"x4.8"

10/100 Ethernet, KB/Mouse,
Watchdog, DiskOnChip®

PCM-4823
EOL

Intel
486® DX4-100

Award/
32 MB
EDO

1 Parallel
SPP/EPP/ECP
1 RS232
1 RS232/485

FDD,
Enhanced
IDE

C&T 65550(PCI)
CRT/LCD
1 MB

PC/104

Half EBX
5.75"x4.0"

10 BaseT Ethernet, KB/Mouse,
IrDA, Watchdog, DiskOnChip®

PCA-6741
EOL

ST Consumer II 133MHz

Award/
32 MB
SDRAM
on-board

1 Parallel
SPP/EPP/ECP
1 RS232
1 RS232/485

FDD,
1 EIDE (UDMA 33)

Built-In
CRT
Shared

PC/104

Half Size ISA Card
7.3"x4.8"

10/100 Ethernet, KB/Mouse,
Watchdog, IrDA,
DiskOnChip®

PCA-6775
EOL

VIA Mark
533/800 MHz

Award Bios
128 MB
SDRAM

1 Parallel
SPP/EPP/ECP
1 RS232
1 RS232/485

FDD,
Enhanced
IDE/SATA
(UDMA 100)

VIA 686B
CRT/LCD
8 - 32 MB Shared

ISA Bus

Half Size ISA Card
7.3"x4.8"

10/100 Ethernet, KB/Mouse, IrDA, USB, LVDS, Watchdog,
CompactFlash™

PCI-6870
EOL

Socket 370 Celeron™/ PIII® up to 1.26 GHz

Award BIOS
512 MB
SDRAM

1 Parallel
SPP/EPP/ECP
1 RS232
1 RS232/485

FDD,
2 EIDE (UDMA 100, & UDMA 33)

Intel 815E CRT/LCD
up to 64 MB shared

PCI Bus

Half Size PCI Card
7.3"x4.8"

10/100 Ethernet, KB/Mouse, Audio,
IrDA, USB,
Watchdog, CompactFlash™

PCM-9340
EOL


ST Elite-133MHz

Award/
32 MB
SDRAM
on-board

1 Parallel
EPP/ECP
3 RS232
1 RS232/485

FDD,
Enhanced IDE

Lynx
EM+ 712
CRT/LCD
2 MB

PC/104

Half EBX
5.75"x4.0"

10/100 Ethernet, KB/Mouse,
IrDA, General Purpose I/O, Watchdog, DiskOnChip®

PCM-3350
EOL

NS Geode
GX-1
300MHz

Award BIOS
256 MB SDRAM

1 Parallel
SPP/EPP/ECP
1 RS232
1 RS232/485

FDD,
Enhanced
IDE

NS CX5530
CRT/LCD
1 ~ 4 MB Shared

PC/104

PC/104
3.55"x3.78"

10/100 Ethernet, KB/Mouse, IrDA, USB, Watchdog, CompactFlash™

PCM-4896L
EOL

NS Geode
GX-1
300MHz

Award BIOS
256 MB SDRAM

1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485

FDD,
Enhanced
IDE
(UDMA 33)

NS CX5530
CRT/LCD
1 - 4 MB Shared

PC/104
PCI Slot

Full EBX
8.0"x5.75"

10/100 Ethernet,
KB/Mouse,Audio, IrDA, USB, Digital I/O, Watchdog, DiskOnChip®

PCM-4897
EOL

NS Geode
233MHz

Award BIOS
128 MB SDRAM

1 Parallel
SPP/EPP/ECP
2 RS232

FDD,
Enhanced
IDE
(UDMA 33)

C&T69000
CRT/LCD
1 - 4 MB Shared

PC/104

8.0"
by
6.4"

KB/Mouse, Audio, TV-Out, IrDA, USB,
Watchdog, DiskOnChip®

PCM-5820
5822
5825

EOL

NS Geode
GX-1
Processors 200MHz/
300MHz

Award BIOS
256 MB SDRAM

1 Parallel
SPP/EPP/ECP
1 RS232
1 RS232/485
PCM-5825
3 RS232/
1 RS232/485

FDD,
Enhanced
IDE
(UDMA 33)

NS CX5530
CRT/LCD
1 ~ 4 MB Shared

PC/104

Half EBX
5.75"x4.0"

10/100 Ethernet, KB/Mouse, Audio, TV-Out, IrDA, USB, LVDS, Watchdog, CompactFlash™

PCM-5823
EOL

NS Geode
GX-1
200MHz or
300MHz

Award BIOS
256 MB SDRAM

1 Parallel
SPP/EPP/ECP
1 RS232
1 RS232/485

FDD,
Enhanced
IDE
(UDMA 33)

NS CX5530
CRT/LCD
1 ~ 4 MB Shared

PC/104

Half EBX
5.75"x4.0"

Dual 10/100 Ethernet, KB/Mouse, Audio, IrDA, USB, Watchdog, LVDS, CompactFlash™

PCM-6240
EOL

VIA Mark
533 MHz

Award Bios
256 MB
DDR RAM

1 Parallel
SPP/EPP/ECP
4 RS232
2 RS232/485

FDD,
Enhanced
IDE
(UDMA 100)

VIA 686B
CRT/LCD
8 - 32 MB Shared

PC/104+

Full EBX
8.0"x5.75"

Dual 10/100 Ethernet, KB/Mouse, USB 1.1,
Watchdog,
CompactFlash™

SBC-657
EOL
Embedded VIA
VIA Eden
667 MHz
Award BIOS
512 MB
SDRAM
1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485
FDD,
Enhanced
IDE
(UDMA 100)
VIA Twister™ Savage4™
CRT/LCD up to 32 MB shared
PISA (ISA/PCI),
PC/104
Half Size PISA
Card
7.3"x4.8"
10/100 Ethernet, KB/Mouse, IrDA, USB, LVDS, Watchdog, CompactFlash™

PCA-6753
EOL

NS Geode
GX-1
300MHz

Award BIOS
256 MB SDRAM

1 Parallel
SPP/EPP/ECP
1 RS232
1 RS232/485
PCA-6753FC
3 RS232/
1 RS232/485

FDD,
Enhanced
IDE
(UDMA 33)

NS CS5535
CRT/LCD
1 - 4 MB Shared

ISA Bus
PC/104

Half Size ISA Card
7.3"x4.8"

10/100 Ethernet, KB/Mouse,
IrDA, USB,
Watchdog, DiskOnChip®

HSB-660S EOL

Intel® PIII® Celeron™ Socket 370 up to
1.4 GHz

Award BIOS
512 MB
SDRAM

1 Parallel
SPP/EPP/ECP
1 RS232
1 RS232/485

FDD,
Enhanced IDE
(UDMA 100)

VIA
VT8606
CRT/LCD
up to 32 MB shared

PISA Bus
(ISA/PCI)
PC/104

Half Size PISA
Card
7.3"x4.8"

Dual 10/100/1000
Ethernet, KB/Mouse, IrDA, USB, Audio, CompactFlash™

HSB-660I EOL

Intel® PIII® Celeron™ Socket 370 up to
1.4 GHz

Award BIOS
512 MB
SDRAM

1 Parallel
SPP/EPP/ECP
1 RS232
1 RS232/485

FDD,
Enhanced IDE
(UDMA 100)

VIA
VT8606
CRT/LCD
up to 32 MB shared

ISA Bus PC/104

Half Size ISA Card
7.3"x4.8"

Dual 10/100/1000
Ethernet, KB/Mouse, IrDA, USB, Audio, CompactFlash™

PCA-6772
EOL
Embedded VIA
VIA Eden 400/667 MHz
Award BIOS
512 MB
SDRAM
1 Parallel
SPP/EPP/ECP
2 RS232

FDD,
Enhanced
IDE
(UDMA 100)
VIA Twister™ Savage4™
CRT/LCD up to 32 MB shared
ISA Bus Half Size ISA Card
7.3"x4.8"
Up to Three 10/100 Ethernets, KB/Mouse,
USB, Audio, WatchDog, CompactFlash™

PCA-6773
EOL

Intel® ULV Celeron™ 400Mhz,
ULV PIII® 650/933 MHz
Award BIOS
512 MB
SDRAM
1 Parallel
SPP/EPP/ECP
1 RS232
1 RS232/485
FDD,
Enhanced
IDE
(UDMA 100)
VIA Twister™ Savage4™
CRT/LCD up to 32 MB shared
ISA Bus
PC/104
Half Size ISA Card
7.3"x4.8"
10/100 Ethernet, KB/Mouse, LVDS, IrDA, USB, Watchdog, CompactFlash™

PCI-6871
EOL

Embedded VIA
VIA Eden
400/667 MHz
Award BIOS
512 MB
SDRAM
1 Parallel
SPP/EPP/ECP
1 RS232
1 RS232/485
FDD,
Enhanced
IDE
(UDMA 33)
VIA Twister™ Savage4™
CRT/LCD up to 32 MB shared
PCI
PC/104
Half Size PCI Card
7.3"x4.8"
10/100 Ethernet, KB/Mouse, Audio, IrDA, USB, Watchdog, CompactFlash
PCI-6881
EOL
Intel® Celeron™M
Pentium M
600 MHz,
1.1 Ghz,
Socket 479
Award Bios
2 Gig
DDR RAM
1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485
FDD,
2 EIDE
(UDMA 33)
(UDMA 100)
Intel 855G
Dual Display
CRT/LCD up to 64 MB shared
PCI Bus Half Size PCI Card
7.3"x4.8"
Gigabit Ethernet, KB/Mouse, Audio,
USB 2.0, GPIO
LVDS, Watchdog, CompactFlash™
PCI-6886
EOL
Intel® Celeron™M
600 MHz
Award Bios
2 Gig
DDR RAM
1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485
FDD,
2 EIDE
(UDMA 33)
(UDMA 100)
Intel 852G
Dual Display
CRT/LCD up to 64 MB shared
PCI
Half Size PCI Card
7.3"x4.8"
Gigabit Ethernet, KB/Mouse, Audio, USB 2.0, LVDS
GPIO, Watchdog, CompactFlash™
PCM-6892
EOL
Intel® ULV Celeron™ 400Mhz,
ULV PIII® 650 MHz
Award BIOS
512 MB
SDRAM
1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485
FDD,
Enhanced
IDE
(UDMA 100)
VIA Twister™ Savage4™
CRT/LCD up to 32 MB shared
PCI Slot
PC/104
Mini PCI
Full EBX
8.0"x5.75"
Dual Ethernet, KB/Mouse, LVDS, IrDA, USB,
TV-Out,
CompactFlash™

PCM-9150
EOL

Socket 479 Intel® Celeron®/ Pentium M up to
2.13 GHz

Award Bios
2 Gig
DDR-II RAM

1 Parallel
EPP/ECP
3 RS232
1 RS232/485

FDD,
1 EIDE
(UDMA 100) 2 SATA 150

Intel 915G
Dual Display
CRT/LCD up to 128 MB shared

PCI Bus
Mini PCI
PCI Exp.

Full EBX
8.0"x5.75"

Dual Gigabit Ethernet, KB/Mouse, Audio, USB 2.0, GPIO, LVDS,
TV-Out, DVI, Watchdog, CompactFlash™

PCM-9371
EOL
Intel® ULV Celeron™ 400Mhz,
ULV PIII® 650/933 MHz
Award BIOS
512 MB
SDRAM
1 Parallel
SPP/EPP/ECP
1 RS232
1 RS232/485
FDD
(Optional),
Enhanced
IDE
(UDMA 100)
VIA Twister™ Savage4™
CRT/LCD up to 32 MB shared
PC/104 Half EBX
5.75"x4.0"
10/100 Ethernet, KB/Mouse, Audio, Optional TV-Out, LVDS, IrDA, USB, Watchdog, CompactFlash™

PCM-9373
EOL

Embedded VIA
VIA Eden 400/667 MHz and C3 1 GHz

Award BIOS
512 MB
SDRAM

1 Parallel
SPP/EPP/ECP
1 RS232
1 RS232/485

FDD (Optional),
Enhanced
IDE
(UDMA 100)

VIA Twister™ Savage4™
CRT/LCD up to 32 MB shared

PC/104

Half EBX
5.75"x4.0"

10/100 Ethernet, KB/Mouse, Audio, Optional TV-Out, LVDS, IrDA, USB, Watchdog, CompactFlash™

PCM-9381
EOL

Intel® Celeron™M
600 MHz,
Pentium M
1.4 GHz
Award Bios
1 Gig
DDR RAM
1 Parallel
SPP/EPP/ECP
1 RS232
1 RS232/485
Enhanced
IDE
(UDMA 100)
Intel 852G
Dual Display
CRT/LCD up to 64 MB shared
PCI-104
Half EBX
5.75"x4.0"
Gigabit Ethernet, KB/Mouse, Audio, USB 2.0, LVDS
IrDA, Watchdog, CompactFlash™

PCM-9578
EOL

Socket 370 Celeron™/ PIII® up to 1.26 GHz

Award BIOS
512 MB
SDRAM

1 Parallel
SPP/EPP/ECP
2 RS232

FDD (Optional),
Enhanced IDE
(UDMA 33)

Intel 815E CRT/LCD
up to 64 MB shared

PCI Slot

Full EBX
8.0"x5.75"

Up to Four 10/100 Ethernets, KB/Mouse,
USB, IrDA, WatchDog, CompactFlash™

PCM-9579
EOL
Intel® ULV Celeron™ 400Mhz,
ULV PIII® 650/933 MHz
Award BIOS
512 MB
SDRAM
1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485
FDD,
2 EIDE
(UDMA 100)
VIA Twister™ Savage4™
CRT/LCD up to 32 MB shared
PC/104+
PCI Slot
Full EBX
8.0"x5.75"
10/100 Ethernet, KB/Mouse, Audio, IrDA, USB,
LVDS, TV-Out, Watchdog, CompactFlash™, DiskOnChip®

PCM-9575
EOL

Embedded VIA
Eden 400MHz/ Ezra 800MHz
Award BIOS
512 MB
SDRAM
1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485
FDD,
2 EIDE
(UDMA 100)
VIA Twister™
Savage4™
CRT/LCD
up to 32 MB shared
PC/104+
PCI Slot
Full EBX
8.0"x5.75"
10/100 Ethernet, KB/Mouse, Audio, IrDA, USB, LVDS, Watchdog, CompactFlash™, DiskOnChip®

PCM-9577
EOL

Socket 370 Celeron™/ PIII® up to 1.26 GHz

Award BIOS
512 MB
SDRAM

1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485

FDD,
2 EIDE (UDMA 100, & UDMA 33)

VIA Twister™
Savage4™
CRT/LCD
up to 32 MB shared

PC/104
PCI Slot

Full EBX
8.0"x5.75"

Gigabit Ethernet, KB/Mouse, Audio,
IrDA, USB 2.0, LVDS, TV-Out, Watchdog, CompactFlash™

PCM-9580
EOL

Socket 478 Intel® Celeron®/ Pentium® 4 up to
3.06 GHz

Award Bios
2 Gig
DDR RAM

1 Parallel
SPP/EPP/ECP
4 RS232

FDD,
2 EIDE (UDMA 100, & UDMA 33)

Intel 845G
Dual Display
CRT/LCD up to 64 MB share

PCI Slot

Full EBX
8.0"x5.75"

Gigabit Ethernet, KB/Mouse, Audio, USB 2.0, LVDS, Watchdog, CompactFlash™

PCM-9581
EOL

Embedded Intel®
Pentium M Processor 1.1/1.6 GHz
Socket 479

Award Bios
2 Gig
DDR RAM

1 Parallel
EPP/ECP
3 RS232
1 RS232/485

FDD,
2 EIDE (UDMA 100, & UDMA 33)

Intel 855G
Dual Display
CRT/LCD up to 64 MB shared

PCI Slot

Full EBX
8.0"x5.75"

Gigabit Ethernet, KB/Mouse, Audio, USB 2.0, GPIO
LVDS, TV-Out, Watchdog, CompactFlash™

PCM-9582
EOL
Intel® Celeron™M
Pentium M
600 MHz,
1.1 Ghz,
Socket 479
Award Bios
1 Gig
DDR RAM
1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485
FDD,
1 EIDE
(UDMA 100) 2 SATA 150
Intel 855G
Dual Display
CRT/LCD up to 64 MB shared
PC/104+
PCI Slot
Mini PCI
Full EBX
8.0"x5.75"
Gigabit Ethernet, KB/Mouse, Audio, USB 2.0, GPIO
LVDS, TV-Out, DVI Watchdog, CompactFlash™
PCM-9587
EOL
Intel® Celeron™M
600 MHz
Award Bios
1 Gig
DDR RAM
1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485
FDD,
1 EIDE
(UDMA 100)
2 SATA 150
Intel 852G
Dual Display
CRT/LCD up to 64 MB shared
PC/104+
PCI Slot
Mini PCI
Full EBX
8.0"x5.75"
10/100 Ethernet, KB/Mouse, Audio, USB 2.0, GPIO
LVDS, TV-Out, DVI, Watchdog, CompactFlash™
PCM-4386
EOL
Intel® Celeron™M
600 MHz,
or 1 GHz
Award Bios
1 Gig
DDR RAM
1 Parallel
SPP/EPP/ECP
3 RS232
1 RS232/485
Enhanced
IDE
(UDMA 33)
Intel 852G
Dual Display
CRT/LCD up to 32 MB shared
PC/104+
EPIC
6.5"x4.5"
Dual Ethernet, KB/Mouse, Audio, USB 2.0, IrDA, Watchdog,
LVDS, GPIO,
CompactFlash™

EM104-i613
EOL

Intel® ULV Celeron™ 400Mhz,
ULV PIII®
650 MHz

Award BIOS
512 MB
SDRAM

1 Parallel
SPP/ EPP/ ECP
1 RS232
1 RS232/485

FDD,
Enhanced
IDE
(UDMA 33)

VIA Twister™ Savage4™
CRT/LCD up to 32 MB shared

PC/104

PC/104
3.55"x3.78"

10/100 Ethernet, KB/Mouse, IrDA, USB, Watchdog, CompactFlash™

EM104-i8523
EOL
Intel® Celeron™M
600 MHz,
Pentium M
1.4 GHz
Award Bios
1 Gig
DDR RAM
1 Parallel
SPP/EPP/ECP
1 RS232
1 RS232/485
FDD,
Enhanced
IDE
(UDMA 33)
Intel 852G
Dual Display
CRT/LCD up to 64 MB shared
PCI/104+
PC/104
Extended
3.8"x4.6"
10/100 Ethernet, KB/Mouse, Audio, USB 2.0, LVDS
Watchdog,




Product pricing, features, and specifications are subject to change without notice.


Copyright © EMAC, Inc.
All Rights Reserved
