COM-BT


  • Intel® Atom™/ Celeron® Processor SoC
  • Up to 8GB DDR3L SODIMM
  • Gigabit Ethernet with Intel® Controller
  • High Definition Audio Interface

COM-BT CPU Board is a 6 COM Express module. It has an eDP interface allowing closed connection between the display device and the board ensuring that it is free from any external interference. COM-BT CPU Board is also capable of converting video signal through DDI0 and DDI1 going to DVI, DP, or HDMI gadgets or devices.

Features




  • Onboard Intel® Celeron® J1900, N2930, N2807 or Atom™ E3800 Series
  • Up to 8GB DDR3L 1066/1333 MHz SODIMM(4GB max for E3815/E3825/N2807)
  • Intel® Gigabit Ethernet
  • CRT, Up to 24-bit Dual-channel LVDS LCD, DP/HDMI
  • High Definition Audio Interface
  • SATA 3.0Gb/s x 2,
  • USB2.0 x6, USB3.0 x1(combine USB2.0 x1)
  • PCI-Express [x1] x 3
  • COM Express Compact Module, Pin-out Type 6, COM.0 Rev. 2.1

System

  • Form Factor COM Express Compact module, Pin-out
  • Type 6, COM. 0 Rev. 2.1
  • Processor Onboard Intel® Celeron® J1900 (2.0GHz), N2930 (1.83GHz), N2807(1.58GHz);
  • Intel® Atom™ Processor E3800 series: Quad core: E3845 (1.91 GHz), Dual core: E3827 (1.75 GHz), Single core: E3815 (1.46 GHz)
  • System Memory DDR3L 1066/ 1333 MHz SODIMM,
  • Max. 8GB (Max. 4GB for E3815/E3825/N2807)
  • Chipset Intel® Celeron® J1900, N2930, N2807 and Atom™ E3800 Series
  • I/O Chipset Intel® Celeron® J1900, N2930, N2807 and Atom™ E3800 Series
  • Ethernet: Intel® I211, Gigabit Ethernet
  • TPM v1.2 (Optional)
  • BIOS AMI BIOS
  • SPI type, 8MB ROM
  • Wake On LAN Yes
  • Watchdog Timer ITE IT8528, 255 levels
  • H/W Status Monitoring Supports CPU Temperature Monitoring
  • Expansion Interface PCI-Express [x1] x 4 (one shared with Gigabit LAN)
  • Power Requirement Nominal: +12V
  • Board Size 3.74" (L) x 3.74"(W) (95mm x 95mm)
  • Gross Weight 0.55 lb (0.25kg)
  • Operating Temperature 32°F ~ 140°F (0°C ~ 60°C)
  • Storage Temperature -40°F ~ 176°F (-40°C ~ 80°C)
  • Operating Humidity 0% ~ 90% relative humidity,
  • non-condensing
  • MTBF 81,000 hours
  • OS Support Windows® 7, Windows® 8, Linux Fedora

Display:

  • Supports CRT/LVDS simultaneous/ dual view displays
  • Chipset Intel® Celeron® J1900, N2930, N2807 and Atom™ E3800 Series Memory Shared system memory up to 512MB/ DVMT 5.0
  • Resolution Up to 2560 x 1600 for HDMI, DisplayPort, VGA
  • LCD Interface Up to18/24 bits dual-channel LVDS

I/O

  • 2x Storage SATA 3.0Gb/s
  • 2x Serial Port (Tx/ Rx only)
  • 6x USB USB2.0, USB3.0(combine USB2.0 x1)
  • Audio High definition audio
  • GPIO Up to 4 in and 4 out

Overview


COM-BT CPU Board is a 6 COM Express module. It has an eDP interface allowing closed connection between the display device and the board ensuring that it is free from any external interference. COM-BT CPU Board is also capable of converting video signal through DDI0 and DDI1 going to DVI, DP, or HDMI gadgets or devices.

COM-BT adopts the latest Intel® Celeron® J1900, N2930, N2807 and Atom™ E3800 Series product family. The system memory deploys with one DDR3L 1066/1333 MHz SODIMM up to 8 GB (4GB max for E3815/E3825/N2807). In addition, Intel® I211 supports Gigabit Ethernet that allows faster network connections. This model applies
four PCI-Express〔x1〕 (one shared with Gigabit LAN). Moreover, two SATA 3.0Gb/s are configured on the COM-BT. COM-BT also equips USB2.0 x6, USB3.0 x1 (combine USB2.0 x1) for flexible I/O expansions.

The display of COM-BT supports up to two independent displays simultaneously. This brand new COM Express Module is developed to cater to the requirements of Automation, Medical, ticket machine, transportation, gaming, KIOSK, and POS/POI applications.

Possible Applications:
Healthcare
Industrial Automation
Security
Retail & Advertising
Test & Measurement
Defense & Governmen

Manuals
COM-BT_Manual.pdf
Data Sheets
COM-BT.pdf

Specifications


Processor
CPU
Intel Atom E3800 Family Processor
Clock Speed
2 GHz
Processor Misc.

Intel® Atom™ E3800 Product Family/Celeron® N2000 Series SoC Processor

  • N2930: Quad core 1.83 Ghz/ 7.5W
  • J1900: Quad Core 2.0 Ghz/ 10W
  • N2807: Dual Core 1.58 Ghz/ 5W
  • E3845: Quad Core 1.91 GHz/ 10W
  • E3825: Dual Core 1.33 GHz/ 8W
Memory
RAM
Up to 8GB DDR3 SODIMM
BIOS/ Bootloader
AMI BIOS
Memory Misc.

SODIMM DDR3L Memory module upto 8GB.

Primary IO
GPIO
8x GPIO
Disk Interface
2x SATA II
Audio
High definition audio interface
Video Out
CRT, LVDS LCD, DDI, eDP(on module, by switch)
Ethernet
Intel® 211 Gigabit Ethernet
USB
1x USB 3.0 & 6x USB 2.0
Serial Ports
2x COM (2-Wire )
Secondary IO
Expansion
Bus Expansion
COM Express Type 6
Bus Misc.

3x PCI-Express[x1] (Gen 2.0)

LPC Bus

SMbus

Misc
Operating Systems
EMAC OE Linux, ROM-DOS 6.22 / MS-DOS 6.22
SOM Type
COM Express Modules

Mechanical and Environmental


Dimensions
Size
3.74" ×3.74" (94mm × 94mm)
Dimensions Misc.
Dimension (L x W) 3.74" x 3.74" (95mm x 95mm)

Pricing


Pricing correct as of January 2021. Please contact EMAC for Current Pricing and Lead Time. Due to volatility in the electronics industry pricing is subject to change.

OEM / Quantity Pricing Available on Request - Less Services

(Single Unit Pricing. Includes: Integration, Setup,Testing, & Enhanced Support)

Product # Description Price
COM-BTA30-001-R COM-BT-A30-0001, COMeCT6, N2930 4x1.83GHz, 2xSATA, 2xCOM, 1xUSB3, 7xUSB2, GbE, VGA, DP, LVDS $291.00
COM-BTA30-002-R COM-BT-A30-0002, COMeCT6, N2807 2x1.58GHz, 2xSATA, 2xCOM, 1xUSB3, 7xUSB2, GbE, VGA, DP, LVDS $261.00
COM-BTA30-003-R COM-BT-A30-0003, COMeCT6, E3845 4x1.91GHz, 2xSATA, 2xCOM, 1xUSB3, 7xUSB2, GbE, VGA, DP, LVDS $309.00
COM-BTA30-006-R COM-BT-A30-0006, COMeCT6, E3825 2x1.33GHz, 2xSATA, 2xCOM, 1xUSB3, 7xUSB2, GbE, VGA, DP, LVDS $271.00
COM-BTA30-008-R COM-BT-A30-0008, COMeCT6, J1900 4x2GHz, 2xSATA, 2xCOM, 1xUSB3, 7xUSB2, GbE, VGA, DP, LVDS $384.00
