PPC-080E


  • Allwinner A40 Cortex™ QuadCore Processor
  • 8" LCD with 1024 x 768 Resolution
  • 1 GB DDR3 RAM; 8 GB NAND FLASH
  • Projected Capacitive 10-Point Multitouch Touchscreen
  • Optional Bluetooth & GPS

The Embedded Touchscreen Series is the cost effective solution for machine control, automation, IOT Monitoring and digital signage. By including pre-installed Android or Linux, a powerful Allwinner A20 Dual Core CPU, numerous interfaces such as USB, serial, network(wired Gigabit LAN with POE, and 802.11 b/g/n Wifi), TTL / UART, Mini-PCIe, HDMI, VGA, GPIO, LVDS and Wide voltage DC–IN. With optional Bluetooth Cellular Modem or GPS connectivity aviliable. Each panel comes with LED backlighting and is backed by warranty for pixel accuracy.

Features


  • Allwinner A40 Cortex™ QuadCore Processor
  • Cortex™ A7 Chipset
  • 1 GB DDR3 RAM; 8 GB NAND FLASH
  • 8" LCD with 1024 x 768 Resolution
  • Projected Capacitive 10-Point Multitouch Touchscreen
  • Optional Bluetooth & GPS
  • Android 4.2, 4.4 & Linux Support, WinCE BSP aviliable (based on project)

Internal Connectors

    • 2x Serial
    • 4x TTL UART
    • 2x USB 2.0
    • 18/24Bit LVDS
    • 24x GPIO
    • 1x Line-In
    • 1x Line-Out
    • 1x Amplifier for 2x 6W loudspeaker
    • 1x SATA-Port
    • 1x RTC

External Connectors

    • 8-18V DC-IN, screwable
    • 2x USB 2.0
    • 1x USB OTG
    • 1x Serial
    • 1x— 10/100/1000Mbit RJ45 Ports with connector for POE
    • 1x Audio-In
    • 1x Audio-Out
    • 1x SD-card
    • 1x SIM-card
    • 1x W-LAN-connector (802.11 b/g/n wi-fi adapter onboard)
    • 1x HDMI

Expansion Slots

    • 1x MiniPCIe

Overview


The Embedded Touchscreen Series is the cost effective solution for machine control, automation, IOT Monitoring and digital signage. By including pre-installed Android or Linux, a powerful Allwinner A20 Dual Core CPU, numerous interfaces such as USB, serial, network(wired Gigabit LAN with POE, and 802.11 b/g/n Wifi), TTL / UART, Mini-PCIe, HDMI, VGA, GPIO, LVDS and Wide voltage DC–IN. With optional Bluetooth Cellular Modem or GPS connectivity aviliable. Each panel comes with LED backlighting and is backed by warranty for pixel accuracy.
The design of the Embedded Touchscreen series follows the application: flat easy to integrate IP65 front and stable rear housing with VESA-75/100 mounting for fixing / integration.
A really cool new Embedded Touchscreen Series is our most cost-effective solution for intelligent machine control, and like all reliably touch devices built for precision and durability.

Manuals
Data Sheets
PPC-080E.pdf

Specifications


Processor
CPU
Allwinner A40 Cortex™ A7 Quad-Core
Clock Speed
1 GHz
Processor Misc.

Optional Processor- Allwinner A40 Cortex™ A7 Dual-Core

Memory
RAM
1GB
RAM Type
DDR3 RAM
Primary Flash
8GB Nand Flash
Secondary Flash
SD card
Memory Misc.

Optional memory options(built to Order options):

  • 2G RAM, 1G Standard
  • 4G to 16G Flash, 8G Standard
  • SATA drive optional
Primary IO
SDIO
1 x SDIO SD Port
Disk Interface
SD CARD
Audio
Integrated HI-FI 100dB Audio Codec
Video Out
HDMI
Ethernet
1x 10/100/1000 BaseT Gigabit Ethernet port (supporting POE)
Wireless
Wireless
Bluetooth
Bluetooth (Optional)
USB
2x USB 2.0
Serial Ports
1x serial
Primary I/O Misc.

External IO connectors:

2x USB 2.0
1x USB OTG
1x Serial
1x 10/100/1000Mbit RJ45 Ports with connector for POE
1x Audio-In
1x Audio-Out
1x SD-card
1x SIM-card
1x W-LAN-Antenna connector (802.11 b/g/n wi-fi adapter onboard) Antenna included.
1x HDMI

Secondary IO
Secondary I/O Misc.

Internal IO (not externally accessable, without modifications)

2x Serial
4x TTL UART
2x USB 2.0
18/24Bit LVDS
24x GPIO
1x Line-In
1x Line-Out
1x Amplifier for 2x 6W loudspeaker
1x SATA-Port
1x RTC

Display
Display Type
LED backlit 8" LCD
Resolution
1024 × 768 px
LCD Colors
16.7M
Viewing Angle
150/150
Luminance
250
Expansion
Bus Misc.

Optional Expansion: (build to order options)

  • Bluetooth 4.0 adaptor
  • GPS-module
  • 3G/4G Cell modem
Misc
Operating Systems
EMAC OE Linux, Android

Mechanical and Environmental


Dimensions
Size
7.91" ×6.32" ×1.4" (200mm × 160mm × 35mm)
Weight
1.4 kg
Power Requirements
Power Misc.

Working Power 8~18V or POE+ (POE Optional)
Power Consumption 7W
Stand-By Consumption  <0.5W

12V DC power supply included.

Environmental
Low Operating Temperature-10 C (14 F)
High Operating Temperature60 C (140 F)
Upper Operating Humidity
90%

Pricing


Pricing correct as of January 2021. Please contact EMAC for Current Pricing and Lead Time. Due to volatility in the electronics industry pricing is subject to change.

OEM / Quantity Pricing Available on Request - Less Services

(Single Unit Pricing. Includes: Integration, Setup,Testing, & Enhanced Support)

Product # Description Price
PPC-080E-0 8" AllWinner A40 1GHz Quad-Core, 1GB RAM, 8GB NAND Flash, 1x COM, 2x USB2, 1x GbE, WIFI, HDMI, Android (-10 to 60*C) $325.00
