SIB-710IVX
- NVIDIA® Jetson™ Xavier NX embedded
- Supports 8CH PoE video input
- Supports 2 x 3.5" HDD
- Low power consumption
- Supports H.264/H.265 cameras
32Spi41141
32Spi81152 SIB-710IVX is the ARM based system which integrated NVIDIA Jetson Xavier NX System-on-Module processor, providing 384 CUDA cores. It is designed for the edge AI NVR support multiple I/O with low power consumption. The system has 8GB LPDDR4 memory, 4K video decode/encode, 8ch POE and 2 x 3.5" HDD expansion.
Features
- NVIDIA® Jetson™ Xavier NX embedded
- ARMv8.2 (64-bit) heterogeneous multi-processing (HMP) CPU architecture | 3x dual-core CPU clusters (six NVIDIA Carmel processor cores) (Max. operating frequency: 1.9GHz)
- Volta GPU, 384 CUDA core, 48 Tensor cores, Performance up to 21 TOPS (INT8) (Max. frequency: 1100MHz)
- Supports 8CH PoE video input
- MICROSEMI PD69104B1ILQ
- IEEE 802.3af
- Supports 2 x 3.5" HDD
- 16GB eMMC flash onboard
- Low power consumption
- Supports H.264/H.265 cameras
Overview
SIB-710IVX is the ARM based system which integrated NVIDIA Jetson Xavier NX System-on-Module processor, providing 384 CUDA cores. It is designed for the edge AI NVR support multiple I/O with low power consumption. The system has 8GB LPDDR4 memory, 4K video decode/encode, 8ch POE and 2 x 3.5" HDD expansion.
| Manuals |
|---|
| Data Sheets | |
|---|---|
| MIC-710IVX_DS.pdf | Download (PDF) |
Specifications
| Processor | |
|---|---|
| CPU | Nvidia Jetson Xavier NX/ ARMv8.2 (64-bit) heterogeneous multi-processing (HMP) CPU architecture 3x dual-core CPU clusters |
| Clock Speed | 1.9 GHz |
| Memory | |
|---|---|
| RAM | 8GB |
| RAM Type | LPDDR4 onboard |
| Primary Flash | 16GB eMMC onboard |
| Secondary Flash | 2x 3.5 |
| Primary IO | |
|---|---|
| GPIO | 4in/4out |
| Disk Interface | SATA 3.5 |
| Video Out | HDMI |
| Ethernet | 1x 10/100/1000 Mbps & 8 POE 10/100 RJ45 |
| USB | 1x USB 3.0 & 1x USB 2.0 |
| Serial Ports | 1x RS485 |
| Primary I/O Misc. | 8 channel POE camera interface |
| Secondary IO | |
|---|---|
| Misc | |
|---|---|
| Operating Systems | EMAC OE Linux |
Mechanical and Environmental
| Dimensions | |
|---|---|
| Size | 11.8" ×13" ×2.2" (299mm × 330mm × 55mm) |
| Weight | 3 kg |
| Power Requirements | |
|---|---|
| Power Misc. | AC100-240V 250W ATX |
| Environmental | |
|---|---|
| Low Operating Temperature | 0 C (32 F) |
| High Operating Temperature | 40 C (104 F) |
| Upper Operating Humidity | 95% |
| Environmental Misc. | 0 ~ 40 °C with 0.7 m/s air flow |
Pricing
Pricing correct as of January 2021. Please contact EMAC for Current Pricing and Lead Time. Due to volatility in the electronics industry pricing is subject to change.
OEM / Quantity Pricing Available on Request - Less Services
(Single Unit Pricing. Includes: Integration, Setup,Testing, & Enhanced Support)
| Product # | Description | Price |
|---|---|---|
| SIB-710IV-X00 | MIC-710IVX, Nvidia Jetson Xavier NX, 8GB DDR4, 16GB eMMC, 2x 3.5" SATA drives, 1x RS485, 1x USB3, 1x USB2, 1x GbE LAN, 8x POE LAN, 4x GPI, 4x GPO, HDMI, 250wPS (0°-40°C) | $1769.00 |
